Johnson Controls LX Series Technical Guide

Table 26: Cool multiplier air handler - 2.5 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
JHETB30DBAS2N1 — 1.02 0.97 0.96
JHETB36DBAS2N1 — 1.03 1.05 0.99
JHETC36DBAS2N1 — 0.99 0.90 0.91
JHVTB36DBAC2N1 — 0.99 0.91 0.93
JHVTC36DBAC2N1 — 1.03 1.01 0.95
JMET12BS2N1A XAFB30C 0.99 0.91 0.91
JMET12BS2N1A XAFB36D 1.03 1.05 0.97
JMET12BS2N1A XAHB30C 1.03 1.06 0.98
JMET12BS2N1A XAUB30C 0.99 0.91 0.91
JMET12BS2N1A XAUB36D 1.03 1.05 0.97
JMET12CS2N1A XAFC30C 1.02 0.98 0.94
JMET12CS2N1A XAHC30C 1.01 0.97 0.95
JMET12CS2N1A XAHC36D 1.01 0.95 0.93
JMET16CS2N1A XAFC30C 1.02 0.98 0.94
JMET16CS2N1A XAHC30C 1.01 0.97 0.93
JMET16CS2N1A XAHC36D 1.01 0.95 0.93
JMVT12BC2N1A XAFB30C 0.99 0.92 0.91
JMVT12BC2N1A XAFB36D 0.99 0.90 0.91
JMVT12BC2N1A XAHB30C 1.01 0.96 0.95
JMVT12BC2N1A XAUB30C 0.99 0.92 0.91
JMVT12BC2N1A XAUB36D 0.99 0.90 0.91
JMVT16CC2N1A XAFC30C 1.01 0.96 0.93
JMVT16CC2N1A XAHC30C 1.01 0.96 0.93
JMVT16CC2N1A XAHC36D 1.02 0.97 0.94
Cool multiplier furnace - 2.5 ton
Table 27: Cool multiplier furnace - 2.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TL8E060A12UH11 XAFA30D 0.99 0.93 0.99
TL8E060A12UH11 XAFB30C 1.01 0.97 0.96
TL8E060A12UH11 XAFB36D 1.01 0.95 0.96
TL8E060A12UH11 XAHB30C 1.00 0.95 0.96
TL8E060A12UH11 XAUB30C 1.01 0.97 0.96
TL8E060A12UH11 XAUB36D 1.01 0.95 0.96
TL8E080C16UH11 XAFC30C 1.01 0.97 0.95
TL8E080C16UH11 XAFC36D 0.99 0.94 0.95
TL8E080C16UH11 XAHC30C 1.01 0.97 0.95
TL8E080C16UH11 XAHC36D 1.01 0.95 0.94
TL8E100C20UH11 XAFC30C 0.99 0.92 0.93
TL8E100C20UH11 XAFC36D 0.99 0.90 0.92
TL8E100C20UH11 XAHC30C 0.99 0.91 0.93
TL8E100C20UH11 XAHC36D 0.99 0.90 0.93
TL9E060B12UH11 XAFB30C 1.00 0.96 0.98
TL9E060B12UH11 XAFB36D 0.99 0.94 0.97
TL9E060B12UH11 XAFC30C 1.00 0.96 0.98
TL9E060B12UH11 XAHB30C 0.99 0.95 0.97
TL9E060B12UH11 XAHC30C 1.00 0.96 0.98
TL9E060B12UH11 XAHC36D 0.99 0.94 0.97
TL9E060B12UH11 XAUB30C 1.00 0.96 0.98
TL9E060B12UH11 XAUB36D 0.99 0.94 0.97
TL9E080C16UH11 XAFC30C 1.01 0.98 0.95
TL9E080C16UH11 XAHC30C 1.01 0.97 0.96
95Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems
