Table 8: Furnace capacity - 2 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B24S21S Z8ES120C20SMPS1S 21.0 XAHC30C 775 24.00 17.60 14.50 12.00
TCD2B24S21S Z8ET060A12LMPS1S 14.5 XAFA24B 625 23.40 15.90 14.00 11.75
TCD2B24S21S Z8ET060A12LMPS1S 17.5 XAFB24B 650 23.60 16.20 14.00 11.75
TCD2B24S21S Z8ET060A12LMPS1S 17.5 XAFB30C 675 23.80 16.70 14.50 12.00
TCD2B24S21S Z8ET060A12LMPS1S 14.5 XAHA24B 625 23.40 15.90 14.00 11.75
TCD2B24S21S Z8ET060A12LMPS1S 17.5 XAHB24B 650 23.60 16.20 14.00 11.75
TCD2B24S21S Z8ET060A12LMPS1S 17.5 XAHB30C 650 23.80 16.50 14.50 12.00
TCD2B24S21S Z8ET060A12LMPS1S 14.5 XAUA24B 625 23.40 15.90 14.00 11.75
TCD2B24S21S Z8ET060A12LMPS1S 17.5 XAUB30C 675 23.80 16.70 14.50 12.00
TCD2B24S21S Z8ET080B12LMPS1S 17.5 XAFB24B 775 24.00 17.30 14.50 12.00
TCD2B24S21S Z8ET080B12LMPS1S 17.5 XAFB30C 775 24.00 17.60 14.75 12.25
TCD2B24S21S Z8ET080B12LMPS1S 21.0 XAFC30C 775 24.00 17.60 14.75 12.25
TCD2B24S21S Z8ET080B12LMPS1S 17.5 XAHB24B 750 23.80 17.00 14.25 12.00
TCD2B24S21S Z8ET080B12LMPS1S 17.5 XAHB30C 750 23.80 17.30 14.50 12.00
TCD2B24S21S Z8ET080B12LMPS1S 21.0 XAHC30C 775 24.00 17.60 14.75 12.25
TCD2B24S21S Z8ET080B12LMPS1S 17.5 XAUB30C 775 24.00 17.60 14.75 12.25
TCD2B24S21S Z8ET080C16LMPS1S 21.0 XAFC30C 700 23.80 16.80 14.75 12.25
TCD2B24S21S Z8ET080C16LMPS1S 21.0 XAHC30C 675 23.80 16.60 14.75 12.25
TCD2B24S21S Z8ET100C16LMPS1S 21.0 XAFC30C 825 24.00 17.90 14.75 12.25
TCD2B24S21S Z8ET100C16LMPS1S 21.0 XAHC30C 800 24.00 17.70 14.75 12.25
TCD2B24S21S Z8ET100C20LMPS1S 21.0 XAFC30C 600 23.60 16.00 14.75 12.25
TCD2B24S21S Z8ET120C20LMPS1S 21.0 XAFC30C 600 23.60 16.00 14.75 12.25
TCD2B24S21S Z8ET120C20LMPS1S 21.0 XAHC30C 600 23.60 16.00 14.75 12.25
Furnace capacity - 2.5 ton
Table 9: Furnace capacity - 2.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B30S21S TL8E060A12UH11 14.5 XAFA30D 875 28.40 20.40 13.50 11.25
TCD2B30S21S TL8E060A12UH11 17.5 XAFB30C 925 29.00 21.40 14.00 11.75
TCD2B30S21S TL8E060A12UH11 17.5 XAFB36D 900 29.00 20.80 14.00 11.75
TCD2B30S21S TL8E060A12UH11 17.5 XAHB30C 900 28.80 21.00 14.00 11.75
TCD2B30S21S TL8E060A12UH11 17.5 XAUB30C 925 29.00 21.40 14.00 11.75
TCD2B30S21S TL8E060A12UH11 17.5 XAUB36D 900 29.00 20.80 14.00 11.75
TCD2B30S21S TL8E080C16UH11 21.0 XAFC30C 925 29.20 21.40 14.25 12.00
TCD2B30S21S TL8E080C16UH11 21.0 XAFC36D 900 28.60 20.60 14.00 11.75
TCD2B30S21S TL8E080C16UH11 21.0 XAHC30C 925 29.20 21.40 14.25 12.00
TCD2B30S21S TL8E080C16UH11 21.0 XAHC36D 900 29.00 20.80 14.25 12.00
TCD2B30S21S TL8E100C20UH11 21.0 XAFC30C 825 28.60 20.20 14.50 12.00
TCD2B30S21S TL8E100C20UH11 21.0 XAFC36D 800 28.40 19.70 14.25 12.00
TCD2B30S21S TL8E100C20UH11 21.0 XAHC30C 800 28.60 20.00 14.50 12.00
TCD2B30S21S TL8E100C20UH11 21.0 XAHC36D 800 28.60 19.80 14.50 12.00
TCD2B30S21S TL9E060B12UH11 17.5 XAFB30C 925 28.80 21.20 13.75 11.50
TCD2B30S21S TL9E060B12UH11 17.5 XAFB36D 900 28.60 20.60 13.75 11.50
TCD2B30S21S TL9E060B12UH11 21.0 XAFC30C 925 28.80 21.20 13.75 11.50
TCD2B30S21S TL9E060B12UH11 17.5 XAHB30C 900 28.60 21.00 13.50 11.50
TCD2B30S21S TL9E060B12UH11 21.0 XAHC30C 925 28.80 21.20 13.75 11.50
TCD2B30S21S TL9E060B12UH11 21.0 XAHC36D 900 28.60 20.60 13.75 11.50
TCD2B30S21S TL9E060B12UH11 17.5 XAUB30C 925 28.80 21.20 13.75 11.50
TCD2B30S21S TL9E060B12UH11 17.5 XAUB36D 900 28.60 20.60 13.75 11.50
TCD2B30S21S TL9E080C16UH11 21.0 XAFC30C 950 29.20 21.60 14.25 12.00
TCD2B30S21S TL9E080C16UH11 21.0 XAHC30C 925 29.00 21.40 14.00 11.75
TCD2B30S21S TL9E080C16UH11 21.0 XAHC36D 925 29.00 21.00 14.25 12.00
TCD2B30S21S TL9E100C20UH11 21.0 XAFC30C 925 29.20 21.40 14.50 12.00
TCD2B30S21S TL9E100C20UH11 21.0 XAHC30C 900 29.00 21.00 14.25 12.00
TCD2B30S21S TL9E100C20UH11 21.0 XAHC36D 875 29.00 20.60 14.25 12.00
TCD2B30S21S TM8E040A12MP11 14.5 XAFA30D 800 28.00 19.60 13.50 11.25
TCD2B30S21S TM8E040A12MP11 17.5 XAFB30C 900 29.00 21.20 14.25 12.00
TCD2B30S21S TM8E040A12MP11 17.5 XAFB36D 875 28.80 20.40 14.25 12.00
TCD2B30S21S TM8E040A12MP11 17.5 XAHB30C 850 28.60 20.60 14.00 11.75
27Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
