Johnson Controls LX Series Technical Guide

Cool multiplier furnace - 4 ton
Table 39: Cool multiplier furnace - 4 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TL8E080C16UH11 XAFC48F 0.99 0.96 0.97
TL8E080C16UH11 XAFC60G 1.01 0.99 0.97
TL8E080C16UH11 XAFD48F 1.00 0.98 0.98
TL8E080C16UH11 XAFD60G 1.01 0.99 0.97
TL8E080C16UH11 XAHC48F 0.99 0.96 0.97
TL8E080C16UH11 XAHC60G 1.01 0.99 0.97
TL8E080C16UH11 XAHD48F 0.99 0.96 0.97
TL8E080C16UH11 XAHD60G 1.00 0.98 0.96
TL8E080C16UH11 XAUC48F 0.99 0.96 0.97
TL8E080C16UH11 XAUC60G 1.01 0.99 0.97
TL8E080C16UH11 XAUD60G 1.01 0.99 0.97
TL8E100C20UH11 XAFC48F 1.00 0.98 0.96
TL8E100C20UH11 XAFC60G 1.02 1.01 0.96
TL8E100C20UH11 XAFD48F 1.00 0.98 0.94
TL8E100C20UH11 XAFD60G 1.02 1.01 0.96
TL8E100C20UH11 XAHC48F 1.00 0.98 0.96
TL8E100C20UH11 XAHC60G 1.02 1.01 0.96
TL8E100C20UH11 XAHD48F 1.00 0.98 0.96
TL8E100C20UH11 XAHD60G 1.02 1.00 0.96
TL8E100C20UH11 XAUC48F 1.00 0.98 0.96
TL8E100C20UH11 XAUC60G 1.02 1.01 0.96
TL8E100C20UH11 XAUD60G 1.02 1.01 0.96
TL9E080C16UH11 XAFC60G 1.00 0.99 1.00
TL9E080C16UH11 XAFD60G 1.00 0.99 1.00
TL9E080C16UH11 XAHC60G 1.00 0.95 0.94
TL9E080C16UH11 XAUC60G 1.00 0.99 1.00
TL9E080C16UH11 XAUD60G 1.00 0.99 1.00
TL9E100C20UH11 XAFC48F 1.00 0.98 0.98
TL9E100C20UH11 XAFC60G 1.02 1.00 0.96
TL9E100C20UH11 XAFD48F 1.00 0.98 0.96
TL9E100C20UH11 XAFD60G 1.02 1.00 0.96
TL9E100C20UH11 XAHC48F 1.00 0.98 0.98
TL9E100C20UH11 XAHC60G 1.02 1.00 0.96
TL9E100C20UH11 XAHD48F 1.00 0.98 0.96
TL9E100C20UH11 XAHD60G 1.01 0.99 0.97
TL9E100C20UH11 XAUC48F 1.00 0.98 0.98
TL9E100C20UH11 XAUC60G 1.02 1.00 0.96
TL9E100C20UH11 XAUD60G 1.02 1.00 0.96
TM8E080C16MP11 XAFC48F 1.00 0.98 0.98
TM8E080C16MP11 XAFC60G 1.01 0.99 0.97
TM8E080C16MP11 XAFD48F 1.00 0.99 0.98
TM8E080C16MP11 XAFD60G 1.01 0.99 0.97
TM8E080C16MP11 XAHC48F 1.00 0.98 0.98
TM8E080C16MP11 XAHC60G 1.01 0.99 0.97
TM8E080C16MP11 XAHD48F 1.00 0.98 0.98
TM8E080C16MP11 XAHD60G 1.01 0.99 0.97
TM8E080C16MP11 XAUC48F 1.00 0.98 0.98
TM8E080C16MP11 XAUC60G 1.01 0.99 0.97
TM8E080C16MP11 XAUD60G 1.01 0.99 0.97
TM8E080C20MP11 XAFC48F 1.00 0.96 0.96
TM8E080C20MP11 XAFC60G 1.02 0.99 0.96
135Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
