Johnson Controls LX Series Technical Guide

Performance data - 2 ton
See the following tables for performance and multiplier data for the TCD2B24S21S unit.
Condenser only performance data - 2 ton
Table 20: Condenser only performance data - 2 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 24.9 0.98 23.4 1.18 21.9 1.37 20.4 1.55 18.9 1.73 17.3 1.89 15.7 2.06
40 118 27.4 0.96 25.8 1.17 24.3 1.37 22.7 1.55 21.0 1.74 19.3 1.91 17.5 2.09
45 130 30.1 0.94 28.5 1.16 26.8 1.36 25.0 1.56 23.2 1.75 21.4 1.94 19.5 2.12
50 142 33.1 0.92 31.3 1.15 29.4 1.36 27.5 1.57 25.6 1.76 23.6 1.96 21.6 2.14
55 156 36.1 0.90 34.2 1.14 32.2 1.36 30.2 1.57 28.1 1.78 26.0 1.98 23.8 2.17
Condenser only performance data notes
• For outdoor unit (condenser) performance only. Data does not include the effects of air handler
power or heat.
• Performance based on 15°F subcooling and 15°F superheat at the outdoor unit base valves:
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
• Maximum recommended condensing temperature is 140°F.
Cooling performance data - 2 ton
Table 21: Cooling performance data - 2 ton - indoor coil: XAFA24BXXN1
IDCFM 600 800 1200
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temperature
entering
outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 22.2 24.8 24.6 27.3 29.9 24.0 26.2 26.0 28.9 31.4 25.9 27.6 27.3 30.4 32.9
S.C. 21.9 19.8 17.0 17.2 14.0 23.7 23.1 19.3 19.7 15.6 25.6 26.3 21.6 22.2 17.3
55
kW 1.36 1.35 1.35 1.31 1.27 1.42 1.41 1.42 1.38 1.34 1.48 1.48 1.49 1.45 1.41
T.C. 21.5 23.7 23.8 26.3 29.2 23.3 25.0 25.1 27.7 30.6 25.1 26.2 26.4 29.1 32.1
S.C. 21.3 19.4 16.5 16.7 13.6 23.0 22.4 18.9 19.2 15.4 24.8 25.4 21.3 21.6 17.1
65
kW 1.51 1.50 1.50 1.48 1.45 1.58 1.58 1.58 1.55 1.53 1.65 1.65 1.66 1.63 1.60
T.C. 20.9 22.6 23.0 25.2 28.5 22.6 23.7 24.3 26.5 29.9 24.3 24.9 25.6 27.8 31.3
S.C. 20.6 18.9 15.9 16.2 13.3 22.3 21.8 18.4 18.6 15.1 24.0 24.6 20.9 21.1 17.0
75
kW 1.67 1.66 1.66 1.65 1.63 1.75 1.74 1.74 1.73 1.71 1.82 1.82 1.83 1.81 1.79
T.C. 20.2 21.6 21.8 24.0 27.2 21.9 22.7 22.9 25.1 28.5 23.5 23.7 24.0 26.3 29.7
S.C. 20.0 18.6 15.5 15.7 12.9 21.6 21.0 17.9 18.1 14.7 23.2 23.4 20.3 20.6 16.5
85
kW 1.84 1.84 1.84 1.84 1.83 1.93 1.93 1.93 1.92 1.91 2.01 2.01 2.02 2.01 1.99
T.C. 19.6 20.7 20.6 22.8 25.9 21.1 21.6 21.6 23.8 27.0 22.7 22.6 22.5 24.8 28.1
S.C. 19.3 18.2 15.1 15.2 12.6 20.9 20.2 17.4 17.6 14.3 22.4 22.3 19.7 20.0 16.0
95
kW 2.02 2.02 2.03 2.03 2.02 2.11 2.11 2.12 2.12 2.11 2.20 2.20 2.21 2.20 2.20
T.C. 18.5 19.5 19.4 21.6 24.4 19.9 20.5 20.3 22.6 25.4 21.3 21.5 21.2 23.5 26.5
S.C. 18.3 17.5 14.6 14.8 12.0 19.7 19.4 16.8 17.1 13.7 21.0 21.2 19.0 19.4 15.3
105
kW 2.26 2.27 2.27 2.27 2.27 2.35 2.36 2.36 2.36 2.36 2.45 2.44 2.45 2.45 2.45
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase84
Johnson Controls Ducted Systems
