Johnson Controls LX Series Technical Guide

Table 12: Furnace capacity - 4 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B48S21S Z8ET120C20LMPS1S 21.0 XAUC48F 1550 47.00 34.40 13.50 11.25
TCD2B48S21S Z8ET120C20LMPS1S 21.0 XAUC60G 1575 47.50 34.90 13.75 11.50
TCD2B48S21S Z8ET120C20LMPS1S 24.5 XAUD60G 1400 47.00 33.10 13.75 11.50
Furnace capacity - 5 ton
Table 13: Furnace capacity - 5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B60S21S TM8E080C20MP11 21.0 XAFC60G 1625 55.00 39.50 13.40 11.00
TCD2B60S21S TM8E080C20MP11 21.0 XAFC60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E080C20MP11 24.5 XAFD60G 1625 55.50 39.50 13.40 11.25
TCD2B60S21S TM8E080C20MP11 24.5 XAFD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E080C20MP11 21.0 XAHC60G 1625 55.00 39.50 13.40 11.00
TCD2B60S21S TM8E080C20MP11 21.0 XAHC60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E080C20MP11 21.0 XAHD60G 1600 55.00 39.00 13.40 11.00
TCD2B60S21S TM8E080C20MP11 24.5 XAHD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E080C20MP11 21.0 XAUC60G 1625 55.00 39.50 13.40 11.00
TCD2B60S21S TM8E080C20MP11 24.5 XAUD60G 1625 55.50 39.50 13.40 11.25
TCD2B60S21S TM8E080C20MP11 24.5 XAUD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E100C20MP11 21.0 XAFC60G 1725 55.50 40.50 13.40 11.00
TCD2B60S21S TM8E100C20MP11 21.0 XAFC60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E100C20MP11 24.5 XAFD60G 1625 55.00 39.50 13.40 11.25
TCD2B60S21S TM8E100C20MP11 24.5 XAFD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E100C20MP11 21.0 XAHC60G 1625 55.00 39.50 13.40 11.00
TCD2B60S21S TM8E100C20MP11 21.0 XAHC60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E100C20MP11 21.0 XAHD60G 1675 55.50 40.00 13.40 11.00
TCD2B60S21S TM8E100C20MP11 24.5 XAHD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E100C20MP11 21.0 XAUC60G 1725 55.50 40.50 13.40 11.00
TCD2B60S21S TM8E100C20MP11 24.5 XAUD60G 1625 55.00 39.50 13.40 11.25
TCD2B60S21S TM8E100C20MP11 24.5 XAUD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E120C20MP11 21.0 XAFC60G 1625 55.50 39.50 13.40 11.00
TCD2B60S21S TM8E120C20MP11 21.0 XAFC60H 1650 55.50 40.00 13.50 11.25
TCD2B60S21S TM8E120C20MP11 24.5 XAFD60G 1650 55.50 40.00 13.40 11.25
TCD2B60S21S TM8E120C20MP11 24.5 XAFD60H 1650 55.50 40.00 13.50 11.25
TCD2B60S21S TM8E120C20MP11 21.0 XAHC60G 1650 55.50 40.00 13.40 11.00
TCD2B60S21S TM8E120C20MP11 21.0 XAHC60H 1650 55.50 40.00 13.50 11.25
TCD2B60S21S TM8E120C20MP11 21.0 XAHD60G 1625 55.00 39.50 13.40 11.00
TCD2B60S21S TM8E120C20MP11 24.5 XAHD60H 1625 55.00 39.50 13.50 11.25
TCD2B60S21S TM8E120C20MP11 21.0 XAUC60G 1625 55.50 39.50 13.40 11.00
TCD2B60S21S TM8E120C20MP11 24.5 XAUD60G 1650 55.50 40.00 13.40 11.25
TCD2B60S21S TM8E120C20MP11 24.5 XAUD60H 1650 55.50 40.00 13.50 11.25
TCD2B60S21S TM8E130D20MP11 24.5 XAFD60G 1800 56.00 41.00 13.40 11.00
TCD2B60S21S TM8E130D20MP11 24.5 XAFD60H 1800 56.00 41.50 13.50 11.25
TCD2B60S21S TM8E130D20MP11 21.0 XAHD60G 1750 56.00 41.00 13.50 11.25
TCD2B60S21S TM8E130D20MP11 24.5 XAHD60H 1775 56.00 41.50 13.50 11.25
TCD2B60S21S TM8E130D20MP11 24.5 XAUD60G 1800 56.00 41.00 13.40 11.00
TCD2B60S21S TM8E130D20MP11 24.5 XAUD60H 1800 56.00 41.50 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 21.0 XAFC60G 1525 55.00 38.50 13.50 11.00
TCD2B60S21S TM8V100C20MP12C 21.0 XAFC60H 1525 55.00 39.00 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 24.5 XAFD60G 1525 55.00 38.50 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 24.5 XAFD60H 1525 55.00 39.00 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 21.0 XAHC60G 1525 55.00 38.50 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 21.0 XAHC60H 1525 55.00 39.00 13.75 11.25
TCD2B60S21S TM8V100C20MP12C 21.0 XAHD60G 1525 55.00 38.50 13.40 11.00
TCD2B60S21S TM8V100C20MP12C 24.5 XAHD60H 1525 55.00 39.00 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 21.0 XAUC60G 1525 55.00 38.50 13.50 11.00
TCD2B60S21S TM8V100C20MP12C 24.5 XAUD60G 1525 55.00 38.50 13.50 11.25
TCD2B60S21S TM8V100C20MP12C 24.5 XAUD60H 1525 55.00 39.00 13.50 11.25
TCD2B60S21S TM8V120C20MP12C 21.0 XAFC60G 1525 55.00 38.50 13.50 11.00
TCD2B60S21S TM8V120C20MP12C 21.0 XAFC60H 1525 55.00 39.00 13.50 11.25
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase66
