Johnson Controls LX Series Technical Guide

Table 11: Furnace capacity - 3.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B42S21S Z8ET080C16LMPS1S 21.0 XAUC48F 1325 40.00 30.10 14.25 12.00
TCD2B42S21S Z8ET100C16LMPS1S 21.0 XAFC42E 1300 40.00 30.40 13.75 11.50
TCD2B42S21S Z8ET100C16LMPS1S 21.0 XAFC48F 1300 40.00 30.00 14.00 11.75
TCD2B42S21S Z8ET100C16LMPS1S 24.5 XAFD42E 1300 40.00 30.40 14.00 11.75
TCD2B42S21S Z8ET100C16LMPS1S 24.5 XAFD48F 1325 40.00 30.20 14.00 11.75
TCD2B42S21S Z8ET100C16LMPS1S 21.0 XAHC42E 1275 39.50 29.90 13.75 11.50
TCD2B42S21S Z8ET100C16LMPS1S 21.0 XAHC48F 1300 40.00 30.00 14.00 11.75
TCD2B42S21S Z8ET100C16LMPS1S 24.5 XAHD42E 1275 39.50 29.80 13.75 11.50
TCD2B42S21S Z8ET100C16LMPS1S 24.5 XAHD48F 1300 40.00 30.00 14.00 11.75
TCD2B42S21S Z8ET100C16LMPS1S 21.0 XAUC42E 1300 40.00 30.40 13.75 11.50
TCD2B42S21S Z8ET100C16LMPS1S 21.0 XAUC48F 1300 40.00 30.00 14.00 11.75
TCD2B42S21S Z8ET100C20LMPS1S 21.0 XAFC42E 1275 40.00 30.10 14.00 11.75
TCD2B42S21S Z8ET100C20LMPS1S 21.0 XAFC48F 1300 40.00 29.90 14.25 12.00
TCD2B42S21S Z8ET100C20LMPS1S 24.5 XAFD42E 1300 40.00 30.30 14.00 11.75
TCD2B42S21S Z8ET100C20LMPS1S 24.5 XAFD48F 1325 40.00 30.10 14.25 12.00
TCD2B42S21S Z8ET100C20LMPS1S 21.0 XAHC42E 1250 39.50 29.60 14.00 11.75
TCD2B42S21S Z8ET100C20LMPS1S 21.0 XAHC48F 1300 40.00 29.90 14.25 12.00
TCD2B42S21S Z8ET100C20LMPS1S 24.5 XAHD42E 1275 40.00 30.10 14.00 11.75
TCD2B42S21S Z8ET100C20LMPS1S 24.5 XAHD48F 1300 40.00 29.90 14.25 12.00
TCD2B42S21S Z8ET100C20LMPS1S 21.0 XAUC42E 1275 40.00 30.10 14.00 11.75
TCD2B42S21S Z8ET100C20LMPS1S 21.0 XAUC48F 1300 40.00 29.90 14.25 12.00
TCD2B42S21S Z8ET120C20LMPS1S 21.0 XAFC42E 1300 40.00 30.40 13.75 11.50
TCD2B42S21S Z8ET120C20LMPS1S 21.0 XAFC48F 1300 40.00 30.00 14.00 11.75
TCD2B42S21S Z8ET120C20LMPS1S 24.5 XAFD42E 1300 40.00 30.40 14.00 11.75
TCD2B42S21S Z8ET120C20LMPS1S 24.5 XAFD48F 1325 40.00 30.20 14.00 11.75
TCD2B42S21S Z8ET120C20LMPS1S 21.0 XAHC42E 1250 39.50 29.70 13.75 11.50
TCD2B42S21S Z8ET120C20LMPS1S 21.0 XAHC48F 1325 40.00 30.20 14.00 11.75
TCD2B42S21S Z8ET120C20LMPS1S 24.5 XAHD42E 1275 39.50 29.80 13.75 11.50
TCD2B42S21S Z8ET120C20LMPS1S 24.5 XAHD48F 1325 40.00 30.20 14.00 11.75
TCD2B42S21S Z8ET120C20LMPS1S 21.0 XAUC42E 1300 40.00 30.40 13.75 11.50
TCD2B42S21S Z8ET120C20LMPS1S 21.0 XAUC48F 1300 40.00 30.00 14.00 11.75
Furnace capacity - 4 ton
Table 12: Furnace capacity - 4 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
TCD2B48S21S TL8E080C16UH11 21.0 XAFC48F 1425 46.50 33.00 13.50 11.25
TCD2B48S21S TL8E080C16UH11 21.0 XAFC60G 1450 47.50 33.80 13.75 11.50
TCD2B48S21S TL8E080C16UH11 24.5 XAFD48F 1450 47.00 33.60 13.50 11.25
TCD2B48S21S TL8E080C16UH11 24.5 XAFD60G 1450 47.50 33.80 13.75 11.50
TCD2B48S21S TL8E080C16UH11 21.0 XAHC48F 1425 46.50 33.00 13.50 11.25
TCD2B48S21S TL8E080C16UH11 21.0 XAHC60G 1450 47.50 33.80 13.75 11.50
TCD2B48S21S TL8E080C16UH11 24.5 XAHD48F 1425 46.50 33.00 13.50 11.25
TCD2B48S21S TL8E080C16UH11 21.0 XAHD60G 1425 47.00 33.40 13.75 11.50
TCD2B48S21S TL8E080C16UH11 21.0 XAUC48F 1425 46.50 33.00 13.50 11.25
TCD2B48S21S TL8E080C16UH11 21.0 XAUC60G 1450 47.50 33.80 13.75 11.50
TCD2B48S21S TL8E080C16UH11 24.5 XAUD60G 1450 47.50 33.80 13.75 11.50
TCD2B48S21S TL8E100C20UH11 21.0 XAFC48F 1475 47.00 33.60 13.75 11.50
TCD2B48S21S TL8E100C20UH11 21.0 XAFC60G 1500 48.00 34.40 14.00 11.75
TCD2B48S21S TL8E100C20UH11 24.5 XAFD48F 1475 47.00 33.60 13.75 11.75
TCD2B48S21S TL8E100C20UH11 24.5 XAFD60G 1500 48.00 34.40 14.00 11.75
TCD2B48S21S TL8E100C20UH11 21.0 XAHC48F 1475 47.00 33.60 13.75 11.50
TCD2B48S21S TL8E100C20UH11 21.0 XAHC60G 1500 48.00 34.40 14.00 11.75
TCD2B48S21S TL8E100C20UH11 24.5 XAHD48F 1475 47.00 33.60 13.75 11.50
TCD2B48S21S TL8E100C20UH11 21.0 XAHD60G 1475 48.00 34.20 14.00 11.75
TCD2B48S21S TL8E100C20UH11 21.0 XAUC48F 1475 47.00 33.60 13.75 11.50
TCD2B48S21S TL8E100C20UH11 21.0 XAUC60G 1500 48.00 34.40 14.00 11.75
TCD2B48S21S TL8E100C20UH11 24.5 XAUD60G 1500 48.00 34.40 14.00 11.75
TCD2B48S21S TL9E080C16UH11 21.0 XAFC60G 1475 47.00 33.80 13.40 11.00
TCD2B48S21S TL9E080C16UH11 24.5 XAFD60G 1475 47.00 33.80 13.50 11.00
55Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase
Johnson Controls Ducted Systems
