Johnson Controls LX Series Technical Guide

Table 18: Cool multiplier air handler - 1.5 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
JMET08BS2N1A XAFB24B 1.00 1.01 0.90
JMET08BS2N1A XAFB24B 1.00 1.05 0.90
JMET08BS2N1A XAHB24B 1.00 1.04 0.90
JMET12BS2N1A XAFB18A 0.99 0.95 0.89
JMET12BS2N1A XAFB18A 1.00 1.01 0.92
JMET12BS2N1A XAFB24B 0.99 0.95 0.89
JMET12BS2N1A XAFB24B 1.00 1.02 0.90
JMET12BS2N1A XAHB24B 1.00 1.01 0.90
JMVT12BC2N1A XAFB18A 1.00 1.00 0.90
JMVT12BC2N1A XAFB18A 1.00 1.05 0.92
JMVT12BC2N1A XAFB24B 1.00 1.01 0.90
JMVT12BC2N1A XAFB24B 1.00 1.05 0.90
JMVT12BC2N1A XAHB24B 1.00 1.05 0.90
Cool multiplier furnace - 1.5 ton
Table 19: Cool multiplier furnace - 1.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TL8E060A12UH11 XAFA18A 1.00 1.02 0.94
TL8E060A12UH11 XAFA24B 1.00 1.03 0.94
TL8E060A12UH11 XAFB18A 0.99 1.03 0.93
TL8E060A12UH11 XAFB24B 1.00 1.04 0.92
TL8E060A12UH11 XAHA18A 1.00 1.02 0.96
TL8E060A12UH11 XAHA24B 1.00 1.03 0.92
TL8E060A12UH11 XAHB24B 0.99 1.04 0.93
TL8E060A12UH11 XAUA18A 1.00 1.02 0.94
TL8E060A12UH11 XAUA24B 1.00 1.03 0.94
TL9E060B12UH11 XAHB24B 0.99 0.92 0.93
TM8E040A12MP11 XAFA18A 1.00 1.04 0.94
TM8E040A12MP11 XAFA24B 0.99 0.95 0.93
TM8E040A12MP11 XAFB18A 0.99 1.04 0.93
TM8E040A12MP11 XAFB24B 0.99 1.05 0.91
TM8E040A12MP11 XAHA18A 1.00 1.04 0.94
TM8E040A12MP11 XAHA24B 1.00 0.96 0.92
TM8E040A12MP11 XAHB24B 0.99 0.97 0.93
TM8E040A12MP11 XAUA18A 1.00 1.04 0.94
TM8E040A12MP11 XAUA24B 0.99 0.95 0.93
TM8E060A12MP11 XAFA18A 1.00 1.00 0.94
TM8E060A12MP11 XAFA24B 1.00 1.00 0.92
TM8E060A12MP11 XAFB18A 1.00 0.97 0.92
TM8E060A12MP11 XAFB24B 1.00 1.05 0.92
TM8E060A12MP11 XAHA18A 1.00 1.04 0.96
TM8E060A12MP11 XAHA24B 1.00 0.99 0.94
TM8E060A12MP11 XAHB24B 1.00 1.00 0.92
TM8E060A12MP11 XAUA18A 1.00 1.00 0.94
TM8E060A12MP11 XAUA24B 1.00 1.00 0.92
TM8E080B12MP11 XAFB18A 1.00 1.05 0.94
TM8E080B12MP11 XAFB24B 1.00 0.95 0.92
TM8E080B12MP11 XAHB24B 1.00 0.95 0.92
TM8E100B12MP11 XAFB18A 1.00 1.01 0.92
TM8E100B12MP11 XAFB24B 1.00 1.02 0.92
TM8E100B12MP11 XAHB24B 1.00 1.00 0.92
TM8V060A12MP12C XAFA18A 1.00 1.01 0.94
Technical Guide: LX Series TCD2B Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase80
Johnson Controls Ducted Systems
