Table 4: 1.5 ton cooling charging chart for XAH24B,
XAH*30C, JH(E,V)*18B, and JH(E,V)T*24C in horizontal
left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base value
55 199 (7) 200 (7) 202 (7) 207 (5)
60 218 (7) 218 (7) 221 (7) 224 (5)
65 236 (6) 236 (7) 239 (6) 241 (5)
70 254 (6) 254 (7) 257 (6) 260 (6)
75 272 (5) 273 (7) 275 (6) 278 (6)
80 295 (6) 295 (7) 298 (6) 301 (6)
85 318 (6) 318 (7) 321 (6) 324 (6)
90 340 (7) 340 (8) 343 (7) 346 (7)
95 363 (8) 363 (8) 368 (7) 369 (7)
100 392 (8) 392 (8) 394 (8) 398 (7)
105 421 (8) 421 (8) 423 (8) 427 (7)
110 450 (8) 450 (9) 452 (9) 456 (8)
115 479 (8) 478 (9) 481 (9) 484 (8)
120 508 (9) 507 (9) 510 (9) 514 (9)
125 538 (9) 537 (9) 539 (9) 543 (9)
Table 5: 1.5 ton cooling charging chart for XA(F,H)*24B,
XA(F,H)*30C, JH(E,V)*18B, and JH(E,V)T*24C in
downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 197 (4) 198 (4) 200 (4) 204 (3)
60 215 (3) 215 (4) 218 (3) 221 (3)
65 233 (3) 233 (4) 236 (3) 238 (3)
70 251 (3) 251 (4) 254 (3) 256 (3)
75 268 (3) 269 (4) 272 (3) 275 (3)
80 291 (3) 292 (4) 294 (3) 297 (3)
85 314 (3) 314 (4) 317 (3) 320 (3)
90 336 (4) 336 (4) 339 (3) 342 (3)
95 358 (4) 358 (4) 363 (4) 364 (4)
100 387 (4) 387 (4) 390 (4) 393 (4)
105 416 (4) 416 (4) 418 (4) 422 (4)
110 445 (4) 444 (5) 447 (5) 450 (4)
115 473 (4) 472 (5) 475 (5) 478 (4)
120 502 (5) 501 (5) 504 (5) 507 (5)
125 531 (5) 530 (5) 532 (5) 536 (5)
Table 6: 2 ton cooling charging chart for XA(F,H)*30C
and JH(E,V)T*24C in upflow and horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 222 (16) 215 (15) 228 (17) 234 (18)
60 243 (17) 239 (16) 250 (18) 255 (18)
65 264 (17) 262 (17) 271 (18) 276 (18)
70 284 (17) 285 (18) 291 (18) 297 (19)
75 305 (17) 308 (18) 312 (18) 318 (19)
80 330 (18) 333 (19) 337 (19) 343 (19)
85 356 (18) 358 (19) 363 (19) 369 (19)
90 381 (18) 383 (19) 388 (19) 394 (20)
95 407 (18) 408 (19) 413 (19) 420 (20)
100 439 (19) 441 (20) 446 (20) 452 (20)
105 472 (19) 474 (20) 479 (20) 485 (20)
110 505 (19) 507 (20) 512 (20) 518 (21)
115 538 (19) 540 (20) 545 (20) 550 (21)
120 571 (20) 573 (21) 578 (21) 583 (21)
125 604 (20) 606 (21) 611 (21) 615 (21)
Table 7: 2 ton cooling charging chart for XA(F,H)*30C
and JH(E,V)T*24C in downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 212 (4) 206 (4) 218 (4) 223 (4)
60 232 (4) 228 (4) 238 (4) 243 (4)
65 251 (4) 250 (4) 258 (4) 263 (4)
70 271 (4) 272 (4) 278 (4) 283 (5)
75 291 (4) 294 (4) 297 (4) 303 (5)
80 315 (4) 317 (5) 322 (5) 328 (5)
85 339 (4) 341 (5) 346 (5) 352 (5)
90 364 (4) 365 (5) 370 (5) 376 (5)
95 388 (4) 389 (5) 394 (5) 401 (5)
100 419 (5) 421 (5) 426 (5) 432 (5)
105 450 (5) 452 (5) 457 (5) 463 (5)
110 482 (5) 484 (5) 489 (5) 494 (5)
115 514 (5) 515 (5) 520 (5) 525 (5)
120 545 (5) 547 (5) 552 (5) 556 (5)
125 577 (5) 579 (5) 583 (5) 587 (5)
R-410A Outdoor Split-System Heat Pump Installation Manual - YH2E / THE2 / RHP143 Series16
