Johnson Controls System 450 Series Technical Bulletin

Table 10: Refrigeration settings
Symbol Settings Default
setting
Description
SP -40°F to 122°F
-40°C to 50.0°C
35°F
1.7°C
Space temperature set point
• The refrigeration output turns off when the refrigerated space
temperature is less than or equal to the set point.
dIFF 1°F to 15°F
1°C to 8.0°C
3°F
1.5°C
Space temperature differential
• Differential is the temperature value, in degrees that is added
to the SP value to provide a cut-on setpoint for the refrigeration
output.
• When the refrigerated space temperature warms to a value equal
to the setpoint plus the differential, the refrigeration output turns
on.
SNF On: Refrigeration ON
OFF: Refrigeration
OFF
CYC: Cycle
Refrigeration
On Sensor 1 failure mode
• The sensor failure defines the action that the control takes if the
Sn-1 space temperature sensor fails.
• CYC turns the refrigeration output ON and OFF at a rate equal to
the average rate of the last four ON and OFF cycles prior to the
sensor failure.
Note: OFF periods during defrost are not included in the
average OFF times. In this mode, the ASD parameter is
observed during the OFF periods.
ASD 0 to 12 min 1 min Anti-short cycle delay:
• The anti-short cycle delay is the equivalent of a minimum OFF time.
• ASD ensures that every time the refrigeration relay, OUTR1 output
turns OFF, the relay output remains OFF for a period of time equal
to what is set on the ASD setting.
• ASD prevents rapid ON or OFF cycling of the compressor. This is
short cycling.
Table 11: Pump down settings
Symbol Settings Default setting Description
• P100 sensor: 0.0 to 100.0
• P110 sensor: -10.0 to 100.0
• P200 sensor: 0 to 200
25 psiON
• P8 Sensor: -1.0 to 8.0
• P15 Sensor: -1.0 to 15.0
1.7 bar
Cut-in setpoint:
The cut-in setpoint is the pressure at which the
compressor turns ON. When the Sn-3 pressure reading
is greater than or equal to the ON setpoint, the
compressor turns ON.
• P100 sensor: 0.0 to 100.0
• P110 sensor: -10.0 to 100.0
• P200 sensor: 0 to 200
15 psiOFF
• P8 Sensor: -1.0 to 8.0
• P15 Sensor: -1.0 to 15.0
1.0 bar
Cut-out setpoint:
The cut-out setpoint is the pressure at which the
compressor turns OFF. When the Sn-3 pressure
reading is less than or equal to the OFF setpoint, the
compressor turns OFF.
SNF • ON: Compressor ON
• OFF: Compressor OFF
ON Sensor 3 fail mode:
Action to take in the event of a pressure sensor failure.
25System 450 Series C450CCU Condensing Unit Control System Technical Bulletin
