Table 24: P499 Series transducers with 1/4 in. SAE 45 flare internal thread with depressor

(Style 47)

Product code Description

P499RCP-101K 0 psig to 100 psig; WHA-PKD3-200C wire harness included.

P499RCP-105C 0 psig to 500 psig; order a WHA-PKD3 type wire harness separately.

P499RCP-105K 0 psig to 500 psig; WHA-PKD3-200C wire harness included.

P499RCP-107C 0 psig to 750 psig; order a WHA-PKD3 type wire harness separately.

P499RCP-107K 0 psig to 750 psig; WHA-PKD3-200C wire harness included.

Table 25: P499 Series transducers with 1/8 in. 27 NPT external thread (Style 49)

Product code Description

P499RAP-101C 0 psig to 100 psig; order a WHA-PKD3 type wire harness separately.

P499RAP-101K 0 psig to 100 psig; WHA-PKD3-200C wire harness included.

P499RAP-102C 0 psig to 200 psig; order a WHA-PKD3 type wire harness separately.

Table 26: P599 Series transducer with 1/4 in. SAE 45 flare internal thread with depressor (Style

47)

Product code Description

P599RCPS102K 0 psis to 200 psis; WHA-PKD3-200C wire harness included.

Table 27: P599 Series transducer with 1/8 in. 27 NPT external thread (Style 49)

Product code Product description

P599RAPS102K 0 psis to 200 psis; WHA-PKD3-200C wire harness included.

Note: Power the P499 and P599 sensors with the +5 VDC and C terminals and the output is 0.5 to

4.5 VDC ratiometric to the +5 VDC supply. Refer to the P499 Series Electronic Pressure Transducers

and P599 Series Electronic Pressure Transducers Product Bulletins.

Table 28: WHA-PKD3 wire harnesses

Product code Product description

WHA-PKD3-200C Plug and 3-wire harness for P499 and P599 electronic pressure transducers; 2 m or 6.5 ft cable

WHA-PKD3-400C Plug and 3-wire harness for P499 and P599 electronic pressure transducers; 4 m or 13 ft cable

WHA-PKD3-600C Plug and 3-wire harness for P499 and P599 electronic pressure transducers; 6 m or 19.6 ft cable
