Actuadores eléctricos con válvula sin retorno por muelle de la serie VA9310 Instrucciones de instalación
5
3. Mantenga presionado el botón de operación del
e
ngranaje.
El actuador debería quedar contra el tope
CCW
interno.
4.
Levante la manilla por encima
del actuador y gire
u
nos 90en sentido antihorario.
5. Vuelva a introducir la
manilla en perpendicular al
actuador y
apriete el tornillo de la manilla. El pa
r
r
ecomendado es de 8 a 12 lb·pulg. (0,9 a 1,4 N·m).
Figura 6: Presione la liberación del engranaje y
vuelva a colocar la manilla en su posición
FIG:Removing Handle
Figura 7: Manilla girada 90
FIG:90 Degree
Figura 8: Apretar la manilla del actuador
FIG:Actuator Perpendicular to Valve
