Johnson Controls VB09 - FIGURE 14 - Optional RA Panel with ADA Mounted Thermostat

23
SECTION 1 - INSTALLATION
FORM 145.18-IOM1
ISSUE DATE: 8/30/2018
1
Magnetic Catches x 2
Notes:
- Powder coated in 'Appliance White'
- Inside panel lined with 1/2" acoustical insulation
- Hinged panel complete with magnetic latches
- Panel comes either Left or Right hand opening
1/2" Insulation
1.25
Thermostat mounting location,
Cut-out for routing
ADA thermostat harness
LEFT HAND OPENING SHOWN
1.50
LD19320
NOTES:
1. Powder coated in appliance white
2. Inside panel lined with 0.5-inch acoustical insulation
3. Hinged panel complete with magnetic latches
4. Panel comes either left or right hand opening
Magnetic Catches x 2
0.5-inch Insulation
1.5 inches
Thermostat mounting location,
cut-out for routing ADA thermostat
harness
1.25 inches
Left Hand Opening Shown
LD19320
FIGURE 14 - OPTIONAL RA PANEL WITH ADA MOUNTED THERMOSTAT
