SECTION 2 - OPERATION
FORM 145.18-IOM1
ISSUE DATE: 8/30/2018
2
TABLE 8 - PSC STANDARD BLOWER PERFORMANCE (CFM)
UNIT
SIZE
MOTOR
SPEED
RATED
CFM
MIN.
CFM
EXTERNAL STATIC PRESSURE (IN W.G.)
0.0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5
09
HIGH
340 220
340 330 320 310 300 285 270 255 240 225 -
LOW 255 250 240 230 220 210 - - - - -
12
HIGH
430 290
445 435 425 415 400 385 370 355 340 320 295
LOW 350 345 335 325 315 305 290 - - - -
15
HIGH
550 335
580 570 560 550 535 520 505 485 465 445 425
LOW 385 380 375 370 365 355 345 335 - - -
18
HIGH
685 430
700 690 675 660 635 615 595 575 550 525 495
LOW 450 445 440 435 430 425 - - - - -
24
HIGH
850 575
880 855 835 815 795 770 740 710 680 650 615
LOW 715 710 705 690 670 650 630 605 580 - -
30
HIGH
1075 700
1115 1100 1075 1050 1020 990 960 930 895 850 800
LOW 965 960 950 935 915 895 870 840 810 780 745
36
HIGH
1220 840
1230 1200 1170 1140 1110 1075 1040 1000 960 915 870
LOW 1115 1100 1075 1050 1020 990 960 930 895 855 805
TABLE 9 - PSC HIGH STATIC BLOWER PERFORMANCE (CFM)
UNIT
SIZE
MOTOR
SPEED
RATED
CFM
MIN.
CFM
EXTERNAL STATIC PRESSURE (IN W.G.)
0.0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 0.55 0.6 0.65 0.7 0.75 0.8
09
HIGH
340 220
375 370 360 350 340 330 315 300 285 265 245 220 - - - - -
LOW 330 320 310 300 290 280 270 255 240 225 - - - - - - -
12
HIGH
430 290
485 475 465 455 440 425 410 395 380 360 340 315 - - - - -
LOW 390 385 380 370 360 350 335 320 305 - - - - - - - -
15
HIGH
550 335
665 650 635 615 595 575 555 540 520 500 475 450 420 395 370 340 -
LOW 580 570 560 550 535 520 505 485 465 445 425 400 375 350 - - -
18
HIGH
685 430
750 735 715 695 675 655 630 605 580 555 525 495 465 435 - - -
LOW 670 655 640 625 605 585 560 535 510 485 460 435 - - - - -
24
HIGH
850 575
990 970 950 930 910 890 865 845 820 795 770 740 710 680 650 615 575
LOW 795 785 775 760 745 730 715 695 675 655 630 605 580 - - - -
30
HIGH
1075 700
1180 1170 1160 1145 1130 1110 1090 1070 1050 1025 1000 970 940 910 875 840 800
LOW 985 980 975 970 960 950 940 935 920 905 895 875 850 825 795 765 730
36
HIGH
1220 840
1340 1320 1295 1270 1245 1220 1190 1160 1130 1100 1070 1040 1010 980 945 910 870
LOW 1180 1170 1160 1145 1130 1110 1090 1070 1050 1025 1000 970 940 910 875 840 800
