FORM 145.18-IOM1
ISSUE DATE: 8/30/2018
SECTION 2 - OPERATION
TABLE 10 - ECM STANDARD BLOWER PERFORMANCE (CFM)
UNIT
SIZE
MOTOR
SPEED
RATED
CFM
MIN.
CFM
EXTERNAL STATIC PRESSURE (IN W.G.)
0.0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5
09
HIGH
340 220
342 317 292 276 259 247 236 228 220 214 207
LOW 278 252 226 212 198 189 180 - - - -
12
HIGH
430 290
463 431 399 378 356 340 324 317 310 299 289
LOW 342 317 292 276 259 247 236 - - - -
15
HIGH
550 335
600 567 534 500 466 445 424 396 367 340 312
LOW 495 447 399 372 346 307 268 - - - -
18
HIGH
685 430
760 726 693 667 642 615 587 574 561 529 497
LOW 600 567 534 500 466 445 424 396 - - -
24
HIGH
850 575
891 863 835 809 784 757 730 689 648 601 554
LOW 760 726 693 667 642 615 587 574 - - -
30
HIGH
1075 700
1131 1105 1079 1058 1037 1016 994 972 949 934 918
LOW 918 894 870 852 835 808 781 762 743 718 -
36
HIGH
1220 840
1265 1235 1206 1184 1163 1141 1118 1085 1051 1008 965
LOW 1065 1037 1009 987 965 949 934 910 886 874 861
TABLE 11 - ECM HIGH STATIC BLOWER PERFORMANCE (CFM)
UNIT
SIZE
MOTOR
SPEED
RATED
CFM
MIN.
CFM
EXTERNAL STATIC PRESSURE (IN W.G.)
0.0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 0.55 0.6 0.65 0.7 0.75
09
HIGH
340 220
411 382 354 334 315 300 286 279 272 263 254 242 231 220 - -
LOW 342 317 292 276 259 247 236 228 220 - - - - - - -
12
HIGH
430 290
554 529 504 477 451 430 408 393 378 360 341 330 319 300 - -
LOW 463 431 399 378 356 340 324 317 310 299 290 - - - - -
15
HIGH
550 335
659 623 587 564 541 511 482 462 441 419 397 372 346 320 - -
LOW 600 567 534 500 466 445 424 396 367 340 312 - - - - -
18
HIGH
685 430
891 863 835 809 784 757 730 689 648 601 554 518 482 446 408 -
LOW 760 726 693 667 642 615 587 574 561 529 497 469 441 412 - -
24
HIGH
850 575
1002 971 940 912 883 854 826 800 774 749 724 698 671 643 615 586
LOW 866 827 789 762 735 708 682 659 636 612 587 571 - - - -
30
HIGH
1075 700
1265 1235 1206 1184 1163 1141 1118 1085 1051 1008 965 913 861 808 756 701
LOW 1065 1037 1009 987 965 949 934 910 886 874 861 839 818 - - -
36
HIGH
1220 840
1462 1418 1375 1331 1287 1241 1194 1153 1112 1053 994 964 934 903 872 840
LOW 1265 1235 1206 1184 1163 1141 1118 1085 1051 1008 965 913 861 - - -
