Johnson Controls VB09 User Manual

5
FORM 145.18-IOM1
ISSUE DATE: 8/30/2018
CHASSIS NOMENCLATURE
PRODUCT CATEGORY
VSCS = Vertical Stacked Heat Pump Chassis
R-410A
UNIT CAPACITY
09 = 0.75 TON
12 = 1 TON
15 = 1.25 TON
18 = 1.5 TON
24 = 2 TON
30 = 2.5 TON
36 = 3 TON
DESIGN SERIES
C = Current Generation
AUTO-FLOW REGULATOR
0 = No Flow Control Valve
B = 1.5 USGPM
C = 2.0 USGPM
D = 2.5 USGPM
E = 3.0 USGPM
F = 3.50 USGPM
H = 4.0 USGPM
J = 4.5 USGPM
K = 5.0 USGPM
L = 6.0 USGPM
M = 7.0 USGPM
N = 8.0 USGPM
P = 9.0 USGPM
R = 10.0 USGPM
AIRSIDE OPTIONS
A = Standard Airside Coil
C = Corrosion Protective Coating
WATERSIDE OPTIONS
C = Standard Water Coil
B = Standard Water Coil with Low Temperature
Option
N = Cupro-Nickel Water Coil
R = Cupro-Nickel Water Coil with Low Temperature
Option
MISCELLANEOUS OPTIONS
O = None
1, 2, 3, 4 5, 6 7 8 9 10 11 12 13
VSCS 12 C 1 0 0 A C 0
VOLTAGE
1 = 208/230-60-1
6 = 265-60-1
WATER VALVE & PUMP OPTIONS
VALVE OPTIONS
VALVE
ONLY
Y-STRAINER
No Water Control Valve
O S
Motorized 2-Way Shut-Off Valve
M Y
Motorized 3-Way Shut-Off Valve
N V
