FORM 145.18-IOM1
ISSUE DATE: 8/30/2018
APPENDIX
NOTES
Air Coil
Airflow Airflow
Coil Inlet (Dry Bulb)
Coil Outlet (Dry Bulb)
Coil Inlet (Wet Bulb)
Coil Outlet (Wet Bulb)
Air Relative Humidity (%)
°F
°F
°F
°F
°F
Expansion Valve
Coaxial
Coil
Reversing Valve
Internal Pump Voltage: L1
L2
Internal Pump Amp Draw: L1
L2
*If installed
Fan Amp Draw: L1
L2
*May only need L1 and L2 lines
L3
Fan Voltage: L1
L2
L3
Fan Motor Speed:
°F
Liquid Line
°F
Water In
psi
°F
Water Out
psi
Water Flow:
GPM
Compressor Amp Draw: L1
L2
*May only need L1 and L2 lines
L3
Compressor Voltage: L1
L2
L3
°F
psi = SAT °F
Superheat
Sub-cooling
Suction
Discharge
Compressor
°F
psi = SAT °F
