MCB LED Indication
Note:
The incline is being
commanded up
Note:
The incline is being
commanded down
Note:
RPM signal from the
speed sensor-magnet
pair.
Light-
Indicates the PCB is commanding the incline
gear to move up. If the User is commanding the incline
to increase and this light is not lit, check cabling, verify proper PCB
operation and replace it if either is defective. If the problem
persists, replace the MCB. If the light is lit but the incline is not
moving, check and verify incline gear and its connection to the
board. If this problem persists replace MCB.
Light-
Indicates the PCB is commanding the incline
gear to move down. If the User is commanding the
incline to decrease and this light is not lit, check cabling, verify
proper PCB operation and replace it if either is defective. If the
problem persists, replace the MCB. If the light is lit but the incline
is not moving, check and verify incline gear and its connection to
the board. If this problem persists replace MCB.
Light-
Indicates the MCB is receiving
the revolution signal from the speed
sensor-magnet pair. If this light is not lit, verify the speed sensor
(reed switch) and magnet installed in the front roller. If this
problem persists, replace MCB.
