Johnson JET7000 - PWM MCB LED Chart

PWM MCB LED CHART
NO.
115V
AC
+12V MTR ILT1 ILT2 M.C.SIG UP DOWN
1
OFF
OFF OFF OFF OFF OFF OFF OFF
2
ON OFF OFF OFF OFF OFF OFF OFF
3
ON OFF ON OFF OFF OFF OFF OFF
4
ON ON OFF OFF OFF OFF OFF OFF
5
ON ON OFF OFF OFF
OFF OR
BLINKING
N/A N/A
6
ON ON ON OFF
ON and
OFF
BLINKING N/A N/A
7
ON ON ON ON OFF
COMES ON
BRIEFLY &
THEN SHUTS
OFF
N/A N/A
8
ON ON ON ON OFF N/A ON OFF
9
ON ON ON ON OFF N/A ON OFF
10
ON ON ON ON OFF N/A OFF ON
11
ON ON ON ON OFF N/A OFF ON
5-2 Revision: 1.0 Date: 2001-06-01
