MCB REPLACEMENT
Tools required:
9 Philips screwdriver
Procedure:
1. remove the motor cover
2. Unplug all the cables and wires connecting to the MCB.
3. With the screwdriver remove the MCB.
4. Replace the MCB and tighten the screws holding the MCB to the frame.
5. Reconnect all the cables and wires to the MCB by referring to the wiring
diagram.
6. Enter the engineering mode, recalibrate the speed of the treadmill.
7. Install the motor cover.
7-1
