CONSOLE CABLE REPLACEMENT
Tools required:
9 Philips screwdriver
Procedure:
1. Remove the console lower cover and
the motor cover .
2. Disconnect the console cable from the
PCB and MCB.
3. Tie the old cable to the new one with a
rigid string.
4. Pull the old cable from the top end until
the new cable pass all the way through
the right console mast. Then let it go to
the console base.
5. Connect the console cable to PCB and
MCB.
6.
Install the console cover and the motor
cover.
7-9
