Jonsered CS 2240 Workshop Manual

English – 9
Introduction and safety instructions
2.10 Symbols on the saw
The symbols below are embedded on the chain
saw.
Choke Lever
Refuelling
Stop button
Filling with chain oil
Air purge
Chain brake, activated (right)
Chain brake, not activated (left)
2.11 Symbols in the Workshop Manual
This symbol warns of personal injury
when the instructions are not followed

Jonsered CS 2240 Specifications

General

Engine Displacement	40.9 cm³
Power Output	1.8 kW
Weight (excluding cutting equipment)	4.4 kg
Chain Pitch	3/8"
Fuel Tank Volume	0.37 liters
Oil Tank Volume	0.25 liters
