Pressure sensors
The pressures in the centring circuit(s) and the steering circuit(s) can be read on both the
remote control and in the service program.
Procedure:
1. Follow the procedure given below.
n 0DA2 = oil pressure in the hydraulic centring circuit.
n 1DA1 = oil pressure in the hydraulic circuit of axle 1
n 2DA1 = oil pressure in the hydraulic circuit of axle 2
n 3DA1 = oil pressure in the hydraulic circuit of axle 3
Part no.: 162014 EN-1
80
Release 07/2020
User manual 2300 EF-S system
