S537 BALL BEARING SERVO
2.3
537 Servo
• Wide spaced ball bearing for precise
movement of your aircraft control
outputs
• A zero deadband amplifier insures
accurate neutral centering
• Low current drain
• Indirect drive feedback potentiometer
gives additional protection from
vibration7
• 3-pole ferrite cored motor
7XP6102 - Introduction
CHAPTER 3: COMPONENT SPECIFICATIONS
SYSTEM SPECIFICATIONS
3.1
TYPE
AIRPLANE HELICOPTER
SYSTEM NAME X-6102A X-6102H
TRANSMITTER BODY NET-K236US Net-K236US
RECEIVER R700 (FM) or R770 (PCM) R700 (FM) or R770 (PCM)
CHARGER NEC-222 NEC-222
AIRBORNE BATTERY 1100mah 1100mah
SERVOS NES-537X4 NES-537X5
ACCESSORIES Standard Switch Standard Switch
12" Aileron Extension 12" Aileron Extension
Charge Jack Charge Jack
Servo Accys Servo Accys
Hex Wrench Hex Wrench
Instruction Manual Instruction Manual
TRANSMITTER SPECIFICATIONS
3.2
TYPE AIRPLANE HELICOPTER
MODEL NUMBER NET-K236US NET-K236US
ENCODER 6–channel computer system 6–channel computer system
RF MODULE 72MHz 72MHz
MODULATION PCM (s) or PPM PCM (s) or PPM
OUTPUT POWER Approximately 750mw Approximately 750mw
CURRENT DRAIN 200mA (70mA with DSC) 200mA (70mA with DSC)
POWER SOURCE 1.2Vx Ni-Cd (9.6V) 600mAh 1.2Vx Ni-Cd (9.6V) 600mAh
OUTPUT PULSE 1000–2000 (1500 Neutral) 1000–2000 (1500 Neutral)
