2 Route Monitoring
2.1 Setting the Safety Contour Alarm/ the Dangerous Detection Alert
1 Click on the [Menu] button on the left tool bar.
The menu is displayed.
2 Click on the [Alert] button on the menu.
The [Alert] dialog box appears.
【Setting up Look-ahead】
3 Select the [Look-ahead] in the classification pane.
The [Look-ahead] dialog is displayed in the edit pane.
4 Select [Use Area(Rectangle)] and/or [Use Area(Sector)] check box.
The alert sounds when the danger detection vector/sector approaches a dangerous object.
This unit can monitor when own ship tries to cross over the preset safety contour or danger area,
or when dangerous objects enter the sector specified around own ship.
