31
4 Suppress the Sea Clutter.
Move the [Sea] slider to the right to enhance the effect of sea anti-clutter.
By clicking on the button next to the slider, the mode can be switched between manual (MAN) and
automatic (AUTO).
Note
[SEA] dial of Keyboard operation unit (Option) is be able to perform the following
adjustment.
• When this dial is turned, the level of sea clutters on the radar image is adjusted.
• When this dial is pressed, the function mode is switched to manual/automatic.
5.7 Adjusting the Gain
1 Click on the [Menu] button on the left tool bar.
The menu is displayed.
2 Click on the [Settings] button on the menu.
The [Settings] dialog box appears.
3 Select [Signal Process (Basic)] in the classification pane.
Set a basic processing method of radar signal.
4 Adjust the Gain.
Move the [Gain] slider to the right to increase the gain.
Note
[GAIN] dial of Keyboard operation unit (Option) is be able to perform the following
adjustment.
• When this dial is turned, the gain of the radar image is adjusted.
5.8 Rejecting the Interference from Other Radar
1 Click on the [Menu] button on the left tool bar.
The menu is displayed.
2 Click on the [Settings] button on the menu.
The [Settings] dialog box appears.
3 Select [Signal Process (Basic)] in the classification pane.
Set a basic processing method of radar signal.
4 Select the effect of Interference Rejection (IR).
[Off] ：IR - OFF
[IR Low] ：IR effect - LOW
[IR Middle] ：IR effect - MIDDLE
[IR High] ：IR effect - HIGH
To Next Page
