JRC JFV-700 Series User Manual

6
1 Configuration
1.1 List of Models
Digit １ ２ ３ ４ ５ ６ ７ ８ ９  101112 1314
ＪＦＶ−７００ＨＰ□□□□□
   ①  ②③ ④⑤
①Model identification
NO: JFV-700 1kw with vertical display.
HP: JFV-700HP 3kw with vertical display.
②Characters used on the display panel
J: Japanese
E: English
③Selection of piezoelectric transducer
Output1kW
WideBeam NarrowBeam
Frequency
ＫＤ Ｋ Rubber ＫＲ Rubber
Output
3kW
２００kHz Ｙ Ｒ Ａ Ｏ Ｆ Ｋ
７５kHz − Ｓ Ｂ Ｐ Ｇ Ｌ
５０kHz Ｚ Ｔ Ｃ Ｑ Ｈ Ｍ
３８kHz − − − − ４ ４
２８kHz − − − − Ｊ Ｎ
Other Ｕ Ｖ Ｗ
200 kHz in the single frequency mode is indicated by an alphabet code
followed by an asterisks (＊). See below.
200kHz：Ｋ＊Other frequencies are indicated as below.
75kHz,50kHz,38kHz､28kHz：＊Ｌ、＊Ｍ、＊４、＊Ｎ
④Identification of input voltage
B: 12/24/32 VDC
J: 100/110/220 VAC
⑤Customized specification
Individual customized specification is indicated by a corresponding code.
Examples
JFV-700E＊ＨJ: 1kw type, for the single frequency of 50 kHz wide beam rubber
type transducer, fabricated per AC specification and employing the
English language for the display panel characters.
JFV-700HPEKMB: 3kw type, for the frequency of 200 to 50 kHz, fabricated per DC
specification and employing the English language for the display
panel characters.
