JTS R-4 User Manual

8
Ear-hook microphone
Model CM-235i CX-504
Output
connector
4P-pin mini XLR
Output
connector
(optional)
3P Mini XLR/3.5 ste-
reo plug/4P Hirose
jack
Frequency
response
50~18,000 Hz 30~18,000 Hz
Directionality
Omni-directionality Cardioid
directionality
Sensitivity -53 ± 3dB -68 ± 3dB
Output
impedance
1.8kΩ 680Ω
Max. sound
pressure
allowed
130dB
Dimensions
(mm)
157mm L x
155mmWx
134mmW
111.3mm L x
285mmWx
55mmW
Weight 17g 56.3g
Model CM-801 / CM-804i CM-8015 / CM-825i
Output
connector
4-pin mini XLR
Output
connector
(optional)
3P Mini XLR/3.5 stereo plug/4P Hirose jack
Frequency
response
60~15,000 Hz 50~18,000 Hz
Directionality Omni-directionality
Sensitivity -64 ± 3dB -53 ± 3dB
Output
impedance
1.8KΩ
Max. sound
pressure
allowed
130dB
