Figure1 Figure2 Figure3
Figure4 Figure5
1. Open the battery cover as indicated by the arrow. (Figure 1)
2. Place 2 AA batteries in the battery compartment according to their
polarity.
(Figure2)
3. Close the battery cover back on.(Figure3)
4. Depending on the type of microphone, insert the 4-pin mini XLR into
MIC IN to nish the installation.
(Figure4)
5. Push Power ON/OFF to turn on. (Figure5)
6. Dene the transmitter parameters according to the instructions.
5-5 Installing transmitter //
UHF PLL Transmitter
