JTS R-4 User Manual

47
◎ ATT: Microphone input attenuation
At oFF No attenuation for
audio input
At on 20dB attenuation for
audio input
Sensitivity: microphone input sensitivity
Normal
sensitivity
GAIN：+15dB
GAIN：+12dB
GAIN：+9dB
GAIN ：+6dB
GAIN：+3dB
GAIN：0dB
GAIN：-3dB
GAIN：-6dB
GAIN：-9dB
GAIN：-12dB
GAIN：-15dB
The sensitivity is at GAIN 0dB (default)
as shown above.
◎ RFP: RF power of the transmitter
rF Lo 10mW(default)
rF Hi 50mW
Two output levels can be chosen
(as per local regulation)
RFP low
RFP Hi
The audio input attenuation is
20dB as shown above.
◎AUTO-OFF: time to turn off microphone automatically (in Mute status)
OFF Deactivated
1 1 minute to auto off
10 10 minutes to auto off
30 30 minutes to auto off
Note: default is 10 minutes.

JTS R-4 Specifications

General

Brand	JTS
Model	R-4
Category	Microphone system
Language	English
