JUKI AF05 - Page 10

ATF Instruction Manual
3
Detailed figure of the section A
23
24
22
25
Figure 1.3
Detailed figure of the section B
26
27
29
28
Figure 1.4
22 X-axis adjustment shaft 26 Lock holder
23 Sprocket wheel 27 Plunger plate
24 Ratchet hook adjustment
eccentric collar
28 Toggle pressure adjustment lock pin
25 Ratchet hook stopper 29 Lock holder Y adjustment lock pin
CAUTION
If you do not have any feeder inspection jigs, do not disassemble any parts.
Without a jig, you cannot make correct adjustment to reassemble the parts.
