4. Options
This chapter describes the options that allow you to use this tape feeder easily.
4.1 Bar Code Tag
This option allows you to paste a bar code mark onto the rear edge of the tape feeder.
You can check the bar code easily even after you attach the feeder onto the feeder bank.
Figure 4.1.1 Bar code tag
4.1.1 Attaching a bar code tag
Fit the protruded portion of the bar code tag into the triangular groove of the tail guide.
Paste the bar code mark on the bar code position.
Bar code tag
Tail guide
Protruded portion of
the bar code tag
Bar code position
Triangular groove of
the tail guide
Figure 4.1.2
