JUKI AF05 - Removing a Tape

ATF Instruction Manual
8
2.1.2 Removing a tape
1) Push the retaining roller arm in the direction indicated in the figure to remove a
tape.
Retaining roller arm
Figure 2.1.13
2) Push the upper cover hook in the direction indicated in the figure to unhook the
upper cover.
Figure 2.1.14
3) Lift up the upper cover in the direction indicated in the figure to remove a tape.
Figure 2.1.15
4) Close the upper cover.
