JUKI APW-895 User Manual

– 145 –
7. Names of switches and switch sensors and installation places
Installation places for the respective switches and sensors are as specified below.
No. Name Connector No. Input No. Remarks
Photo sensor for binder upper detection INT CN71A IN-41
Micro switch for binder opening detection INT CN68A IN-38
Cylinder sensor for center knife lifting detection INT CN79A IN-49
Proximity sensor for needle thread trimming detection (left) INT CN62A IN-32
Proximity sensor for needle thread trimming detection (right) INT CN63A IN-33
Reflex optical sensor (left) for flap material end detection INT CN60B IN-60
Reflex optical sensor (right) for flap material end detection INT CN61B IN-61
Pause SW INT CN69B IN-69
Pedal hole pot sensor INT CN75B —
Knee start switch INT CN65B IN-65
Air pressure detecting switch MAIN CN30 IN-00
Photo sensor for back-tack motor origin MAIN CN38 IN-94
Photo sensor for marking light motor origin MAIN CN36 IN-29
Photo sensor for marking light 2nd origin INT CN75A IN-45
Air cylinder sensor for clamp origin INT CN83B IN-92
Air cylinder sensor for material wiper origin INT CN83B IN-90
Micro switch for stacker opening detection INT CN83B IN-83
Reflex optical sensor (left) for bobbin thread remaining amount detection INT CN64B IN-64
Reflex optical sensor (right) for bobbin thread remaining amount detection INT CN64B IN-93
Photo sensor for clamp foot origin detection INT CN77A IN-47
Sensor for clamp foot step-out detection INT CN66A IN-36
Reflex optical sensor for stacker material detection INT CN65A IN-35
Cylinder sensor for roller stacker lifting detection MAIN CN49 IN-91
Photo sensor for corner knife opening motor origin MAIN CN37 IN-28
Cylinder sensor for upper detection of fixed-side corner knife INT CN80B IN-80
Cylinder sensor for lower detection of fixed-side corner knife INT CN79B IN-79
Cylinder sensor for upper detection of moving-side corner knife INT CN82B IN-82
Cylinder sensor for lower detection of moving-side corner knife INT CN81B IN-81
Micro switch for corner knife drawer detection INT CN62B IN-62
