– 178 –
(5) Consumable replacement components
Center knife
Thread guide
felt
Corner knife
Reflecting tape
Garment body
clamp rubber
Flap presser
rubber
Dart stretcher
presser rubber
The components below are the consumable ones.
Periodically replace them.
o Thread guide felt (Part No. : 40034444)
The part where thread presses is worn out and rough
motion of thtead is apt to occur unless it is periodicallt
replaced.
o Center knife (Part No. : 40026155)
oCorner knife (Part Nos. : 16607301 and 16607400)
Sharpness s deter orated and sewing quality s influenced
unless it is periodically replaced.
o Reflecting tape (Part No. : 40039942)
Accuracy of detection of flap is deteriorated and sewing
quality is influenced unless it is periodically replaced.
o Garment body clamp rubber (Part No. : 40034825)
o Flap presser rubber (Part No. : 40034826)
Pressing of material is deteriorated and sewing quality
is influenced unless it is periodically replaced.
o Dart stretcher presser rubber (Part No. : 40034733)
Pressing of material is deteriorated and sewing quality
is influenced unless it is periodically replaced.
To Next Page
