– 1 –
No. Application
APW-895
1 Sewing machine LH-895 model of 2-needle, lockstitch machine with a center knife
2 Sewing speed Max: 3,000 rpm
Lockstitch : 2.0 to 3.4mm (standard :2.5mm)
Condensation stitch : 0.5 to 1.5mm (standard : 1.0mm)
Back tuck stitch : 0.5 to 3.0mm (standard : 2.0mm)
Condensation/Back tuck stitch selectable
Parallel duble welt, parallel single welt
Each with flap or without flap
Possible to set in increments of 0.1mm ithin the range of 18mm (min.) to 220mm (max.) (Needle gage: 8 to 20mm)
Note that the pocket length is 35mm at the minimum when using the corner knife
5 (50mm in case of 14mm gauge or more and 21mm by adding a solenoid valve)
For the longer type (optonal), the maxmimum sewing length will be 250mm (Needle gage: 22 to 32mm)
(Possible up to 300mm wihiout entering corner knife)
Welting width 8, 10, 12, 14, 16, 18 and 20mm
(Needle gauge) (Optional : 22, 24, 26, 28, 30 and 32mm)
7 Needles ORGAN DP X 17 #14 to #18 (standard #16), SCHMETZ 190R #100 to #110 (standard #100)
8 Thread Spun thread #60 (Recommended)
9 Hook Vertical-axis 1.7-fold capacity hook
10 Thread take-up lever Slide thread tak-up lever
11 Needle bar stroke 33.3mm
12
Cloth feed mechanism
Driver by stepping motor
13 Control By a micro-computer
Machine operation is automatically stopped if the cloth feed mechanism error detector, the needle
thread breakage detector or anu of the various safety devices is actuated.
15 Lubricating oil JUKI New Defrix Oil No. 1 (equivalent to ISO VG7)
16 Grease 1. JUKI Grease A. 2. JUKI Grease B
17
Operating air pressure
Standard : 0.5MPa
18 Air consumption 40dm
3
/min(ANR)
Dimensions of Width: 1,095 mm Length: 1,500 mm Height: 1,200 mm
machine (Width: 1,580 mm, including stacker) (Height: 1,800 mm, including thread stand)
20 Weight 238.5kg
21 Temperature: 5°C to 35°C, Humidity: 35 to 85% (no condensation)
1. Specifications
(1) Machinical specifications
3 Stitch length
4 Types of welt
Pocket lip length
(Welt length)
6
19
(2) Electric specifications
Once setting has been made, data can be retained (for 100 hours) by the built-in battery cell even after Power OFF
unless this setting is canceled, thanks to the function of the built-in microcomputer.
No. Application
APW-895
1 No. of patterns for stored single sewing 99 (1 to 99)
2 No. of patterns for stored alternate sewing 20 (1 to 20)
3 No. of stored cycles 20 (1 to 20)
Single phase/3-phase 200 V, 220 V, 230 V, 240 V (option 380 V)
4 Input voltage/frequency 50/60 Hz
Power voltage fluctuation Rated voltage ±10% or less
5 Power consumption 200VA
Model name
Item
Model name
Item
14 Safety mechanism
Working temperature/
humidity
