– 42 –
No. Item name Input range
S073
*
1
Cloth puller pressure
when detecting no mate-
rial
–
90 to
120
S074
Number of stitches at
which the cloth puller
starts running on the top
end of material
0 to 200 stitches
This data item is used for setting the number of stitches
to be sewn from the time at which the presence of mate-
rial is detected to the time at which the top of material is
brought to the cloth puller.
S075
Number of stitches while
the cloth puller runs on
the top end of material
0 to 200 stitches
This data item is used for setting the number of stitches
to be sewn while the cloth puller runs of the top end of
material.
S076
Cloth pulling amount
when the cloth puller
runs on the top end of
material
1.2 to 5.5mm
This data item is used for setting the cloth pulling amount
to be used while the cloth puller runs on the top end of
material.
S077
*
3
Cloth puller pressure
when the cloth puller
runs on the top end of
material
–
90 to
120
This data item is used for setting the cloth puller pres-
sure to be applied while the cloth puller runs on the top
end of material.
S078
*
2
Presser foot pressure
when the cloth puller
runs on the multi-layered
section
–
350 to 200 -
This data item is used for setting the presser foot
pressure to be applied while the cloth puller runs on the
multi-layered section of material
*1: The actual sewing speed is limited by "S003 Stitch length" and the set value of cloth pulling amount.
In the case the set value of stitch length is 3.1 mm or more: Maximum sewing speed 5000 sti/min
In the case the set value of cloth pulling amount is 4.6 mm or more: Maximum sewing speed 4000 sti/min
*2: If this value is set to a negative value (minus value), the presser foot will go up. If the presser foot height is set so
that it oats, the multi-layered section changeover function will be disabled.
*3: If this value is set to a negative value (minus value), the cloth puller will go up.
