– 7 –
7) After inserting the connector, put all cords together
with cable clip band
󱢸
located on the side of the
box.
(Caution) 1. Fix the cord clamp and the cable clip
band following the attaching proce-
dure.
2. When removing the connector, re-
move it from the wire saddle and
remove it while pressing the hook of
the cable clip band.
[ Connection of the pedal of standing-work machine ]
Connect the connector of PK70
󱢶
to connector
󱢷
(CN39 : 12P) of SC-920.
(Caution) Be sure to turn OFF the power before
connecting the connector.
8) Close cover
and x the cover by tightening screw
B
with a screwdriver.
(Caution) Take care not to allow the cord to be
caught under cover
.
B
How to x cable clip band
How to remove cable clip band
Pushing the
hook portion,
push the band
to remove it.
Pull
Push
Push the
hook.
Panel
Panel
9) Connect connector 4P
󱢹
to connector
󱢺
locat
ed
on the side of the box.
10) Connect motor
outpu
t cord
󱢻
of the power switch to
connector
󱢼
.
11) Bundle the machine head cables with a cable clip
󱢽
supplied with the operation panel at one location
as shown in the gure.
󱢷
󱢶
󱢸
󱢺
󱢻
󱢼
󱢹
󱢽
