Command Parameter Response of circulator
none Temperature value registered by the external Pt100 sensor.
IN_PV_03
none Temperature value registered by the safety sensor.
IN_PV_04
none Setpoint temperature (“SafeTemp”) of the excess
Working temperature “Setpoint 1”
none Working temperature “Setpoint 2”
none Working temperature “Setpoint 3”
High temperature warning limit “OverTemp”
none Low temperature warning limit “SubTemp”
IN_SP_05
none Setpoint temperature of the external programmer
none Temperature indication in °C or °F
IN_SP_07
none 1. Adjusted pump stage in the -OFF- condition.
2. Pump stage corresponding to the effective rotational
none Value of a flow rate sensor connected to the E-Prog input
Value of a pressure sensor connected to the E-Prog input
IN_PAR_00
none Temperature difference between working sensor and safety
IN_PAR_01
none Te - Time constant of the external bath.
none Ti - Time constant of the internal bath.
IN_PAR_04
none CoSpeed - Band limit (max. difference between the
temperatures in the internal bath and external system).
IN_PAR_05
none Factor pk/ph0:
Ratio of max. cooling capacity to max. heating capacity
none Xp control parameter of the internal controller.
none Tn control parameter of the internal controller.
IN_PAR_08
none Tv control parameter of the internal controller.
IN_PAR_09
none Xp control parameter of the cascade controller.
Proportional share of the cascade controller.
none Tn control parameter of the cascade controller.
IN_PAR_12
none Tv control parameter of the cascade controller.
IN_PAR_13
none Adjusted maximum internal temperature of the cascade
IN_PAR_14
none Adjusted minimum internal temperature of the cascade
none Band limit (upper)
IN_PAR_16
none Band limit (lower)
