Technical specifications
30
Bridge mounted circulator MW-Z
Usable immersion depth from 90 to 145 mm
Overall dimensions (WxDxH) 320x170x320 mm
Weight 5.5 kg
Heating circulators MV/MW-4 MV/MW-6
Bath opening mm 130x150 130x150
Bath depth mm 150 200
Filling volume liters 3 ... 4.5 4.5 ... 6
Overall dimensions mm 210x410 210x410
(WxDxH) x370 x430
Weight kg 9 / 9 14
Heating circulators MV/MW-12 MV/MW-26
Bath opening mm 220x150 220x300
Bath depth mm 200 200
Filling volume liters 7.5 ... 12 18 ... 26
Overall dimensions mm 300x410 360x610
(WxDxH) x450 x450
Weight kg 15 20
Safety Installations (DIN 12876)
Excess temperature protection adjustable from 20 to 210 °C
Low liquid level protection float switch
Safety class III
Supplementary safety installations:
High temperature warning function optical + audible (in intervals)
Low temperature warning function optical + audible (in intervals)
Supervision of the working sensor plausibility control
Reciprocal sensor monitoring between
working and safety sensors difference >25 °C
Alarm indication optical + audible
Standards:
EMC regulations EN 61326
Guideline for first voltage range EN 61010-1, EN 61010-2-010
