Preparations
8
Recommended tubing:
Temperature range
CR tubing
Viton tubing
-20 °C to +120 °C
-50 °C to +200 °C
5.3. Filling / draining
Filling
Take care that no liquid enters the interior of the
circulator.
• Recommended maximum filling level with water as
bath liquid: 25 mm below the tank rim
• Recommended maximum filling level with bath oils:
40 mm below the tank rim
ATTENTION: the volume of bath oils will increase due to
thermal expansion when the bath temperature rises.
Exercise CAUTION when emptying hot bath liquids!
Draining
• Press the mains switch to turn the circulator off.
• Place the heating circulator near the rim of the table.
Use a suitable vessel as recipient for the bath liquid.
• A drain plug is located on the front of the bath tank
that is unscrewed to drain the bath.
• Remove the bridge mounted circulator from the bath
tank.
• Empty the bath tank.
Store and dispose the used bath liquid according
to the laws for environmental protection.
