Fault signal LED
This lights up as soon as the recording is interrupted by the “end
of chart paper”, “stop” through pressing stop key S , or by an
external stop.
24-character green LED
dot-matrix display
Print head
Keys for
operating und programming
Setup interface
(behind the swing-up
LED dot-matrix)
Panel-mounting housing to IEC 61554 in galvanised steel sheet
Measurement channel label
Here you can enter the channel designation and/or the
corresponding measurement range
Chart paper
Housing door
to open or close
