71
6 Installation
6.1 Site and climatic conditions
The installation site should be as free as possible from vibration. Stray electro-
magnetic fields, for instance those caused by motors, transformers and the
like, should be avoided where possible.
The ambient temperature at the installation site must not go outside the range
0 to +50°C, at a relative humidity of 20 — 70%. No condensation is permitted.
Corrosive gases or vapour can affect the functioning and the operational life of
the printing recorder.
v Section 7.1 “Installation notes”
6.2 Assembly in a control panel
Views
Dimension 26 increased to 27 when using the IP65 seal.
Panel
cut-out
