5 Identifying the instrument version
70
5.2 Order details
Programming
accessories
Standard
accessories
- 1 Operating Manual B 70.6030.0
-2 fixing brackets
- cable-tie with foot (can be released) for tension relief
of the sensor leads connected
- one 3-colour print head (for 3-channel recorder)
or
one 6-colour print head (for 6-channel recorder)
- 1 roll of chart paper, 32m long
and
1 block of fanfold paper, 16m long
(1) Basic version
706030/14 LOGOPRINT 500 with 3 universal inputs
706030/15 LOGOPRINT 500 with 6 universal inputs
(2) Inputs 1 — 3 (configurable)
x x 888 factory setting
x x 999 configuration to customer specification
1
(3) Inputs 4 — 6 (configurable)
x 000 not used
x 888 factory setting
x 999 configuration to customer specification
1
(4) Interface
x x 00 not used
x x 52 RS422, Jbus, MODbus
x x 53 RS485, Jbus, MODbus
(5) Supply voltage
x x 22 20 — 53V AC/DC, 48 — 63Hz
x x 23 110 — 240V AC +10/-15%, 48 — 63Hz
(6) Extra codes
x x 020 lithium battery for memory buffering (ex factory)
x x 021 storage capacitor (instead of extra code 020)
x x 030 terminal with shunt (6 items)
x x 259 8 logic inputs, interface for external
relay module ER8, voltage output
24V DC 50mA
x x 265 door with lock (IP54)
x x 266 IP65 seal, wide mounting brackets
x x 350 universal portable housing TG-35
2
x x 351 housing with carrying handle
3
x x 247 housing for wall mounting (can be rotated through 90°)
3
(1) (2) (3) (4) (5) (6)
Order code ----/
,...
4
Order example 706030/14 - 888 - 000 - 00 - 23 / 020
1. Please specify probe types and ranges in plain text.
2. This extra code is available in combination with supply voltage 110—240V AC, not with low sup-
ply voltage. UL approval is not available. The protection type in the carrying case corresponds to
IP20, outside IP20D.
3. UL approval is not available.
4. List extra codes in sequence, separated by commas.
- Setup program, multilingual
- PC interface with TTL/RS232 converter
- PC interface with USB/TTL converter, adapter (socket) and adapter (pins)
