JUMO LOGOPRINT 500 - Configuration Level 3 (C3-Level)

4 Configuration table
66
4.2.5 Configuration level 3 (C3-level)
Parameter Value/selection Description
Relay output Configuration level 3
➔ Relay output
X Relay 1 — 8 Select relay
Status: OFF, ON OFF = relay inactive
ON = relay operates as an
LK output
Mathematical
module
Configuration level 3
➔ Mathematical module
Mathematical m.: OFF, ON Activate/de-activate
mathematics module
Interface Configuration level 3
➔ Interface
Protocol: J-BUS, MOD-BUS
Set up RS422/RS485
Select protocol
Baud: 0.15, 0.3, 1.2, 2.4, 4.8, 9.6,
19.2, 38.4, 125,
187.5kBaud
Select baud rate
Data format: 8/1/NO,
8/1/ODD,
8/1/EVEN,
8/2/NO,
8/1/ZERO
Select data format
(Data bits / stop bits /
parity)
Address: 1 — 255 Select address
Min. response time: 0 — 500msec. Select minimum response
time
External text Configuration level 3
➔ External text
X External text 1 — 8 Select the number of the
external text
Contact: OFF, Log. input 1,
Log. input 2, Log. input. 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8
Select logic input.
(if OFF: the text entry is not
required)
Text: 16 characters Enter text
Binary-linked
external text
(text logic links)
Configuration level 3
➔ Text logic links
Link: OFF, Log. input 1,
Log. input 1-2,
Log. input 1-3,
Log. input 1-4
Select the inputs which are
to be binary-linked, (if OFF,
all further sub-parameters
are not required)
