4 Configuration table
Text logic links 00 — 01 (Log. input 1)
00 — 03 (Log. input 1-2)
00 — 07 (Log. input 1-3)
00 — 15 (Log. input 1-4)
Select binary combination
(text-no.)
Text status: OFF, ON Select the status for the
text printing
Text: 16 characters Enter text
External stop Configuration level 3
➔ External stop
Contact: OFF, Log. input 1,
Log. input 2, Log. input 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8
Select logic input
External speed Configuration level 3
➔ External speed
Contact: OFF, Log. input 1,
Log. input 2, Log. input 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8
Select logic input
External speed: 0, 5, 10, 20, 60, 120, 240,
300, 360, 600, 720mm/h
Select speed when
contact <> OFF
Event counter Configuration level 3
➔ Event counter
X Event counter 1 — 2 Select event counter
Contact: OFF, Log. input 1,
Log. input 2, Log. input 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8
Select logic input or
status (if OFF: all the fol-
lowing sub-parameters are
not required)
EC status: OFF, ON Select status
Start value: -99999 to +99999 Enter start value for the
event counter
Text: 16 characters Text for designation of the
event counter
External scaling Configuration level 3
➔ External scaling
Contact: OFF, Log. input 1,
Log. input 2, Log. input 3,
Log. input 4, Log. input 5,
Log. input 6, Log. input 7,
Log. input 8
Select logic input
Parameter Value/selection Description
