3 Operation and visualisation
48
3.5.12 Incrementing the two event counters
The event counter is assigned to a freely selected logic input. Every time the
corresponding logic input is closed, the event counter is incremented. It can
be pre-loaded with a value through the setup program and the keys on the re-
corder (Configuration level 3
Î Event counter).
Every time it is incremented, the event is registered by printing the time and
the programmed text, followed by the current state of the counter.
The time reference mark “_” will not be printed, since the print-out
may appear after being delayed in the print queue.
v Section 3.5.4 “Limit comparator texts, external text, binary-
linked external text”
If the counter state is larger than 99999, then the number can no
longer be displayed. The print-out will be “ ***** “ for the counter
state.
