6 Installation
72
Mounting h Insert the recorder from the front into the panel cut-out.
h From the back of the panel, hook the two mounting brackets into the cut-
outs in the sides of the housing. The flat faces of the brackets must lie
against the housing.
h Place the brackets against the rear of the panel, and tighten them evenly.
Fixing bracket
