2 Instrument description
18
Example of the basic status for a 6-channel recorder
Operating level
(S-level)
The operating level can be accessed from the basic status with the aid of the
h + R keys, from the parameter level by using e.
Signal acquisition and processing remain active in this level.
The following parameters can be altered:
- chart speed
-print test
- service print
- version number (display only)
BUILDING28 03.11.98 08 : 54 Display instrument name, date and time
hR
1 -5.321m/h 2 +34.67°C Display the first 2 channels in one frame
hR
3 +76.20°C 4 +20.35bar Display the next two channels in one frame
hR
5 +35.08°C 6 +007.4U/m Display the next two channels in one frame
hR
1 CONVEYOR -5.321m/h Display the 6 channels, each in a separate frame
hR
2 MIXER +34.67°C
hR
3 MOT7. BEARING +76.20°C
hR
4 PRESSURE +20.35 bar
hR
5 VENT.TEMP. +35.08°C
hR
6 SHAFT +007.4U/m
It the operating level is active, then signal acquisition, processing
and recording, as well as limit monitoring, will all continue to be
performed.
