4 Configuration table
54
Example 2 Starting from example 1, the instrument designation is to be changed.
l
Key Display Description
S-LEVEL
h + R Start code check
CODE: 9200 Enter 9200, by using the l, r, h, R
keys
E Conclude entry of code number
P-LEVEL
h + R Call up configuration level 1
C1-LEVEL
h + R Call up configuration level 2
C2-LEVEL
h Call 1st. parameter of this level
UNIT NAME (the name of the instrument)
E Call the parameter to be altered
TEXT: LOGOPRINT 500 Enter the new designation (UNIT
NAME), using the l, r, h, R and S
keys
E Confirm instrument designation
UNIT NAME Parameter entry is finished
e Leave level
C1-LEVEL
e Leave level
P-LEVEL
e Leave level
INITIALISATION As long as the display is flashing,
the recorder is being initialised
with the new data
S-LEVEL Recorder is in the operating level
again
e Leave operating level
LOGOPRINT 03.11.98 09:45 Recorder is in basic status again
