4 Configuration table
64
Print the time Configuration level 2
➔ Print time
Spacing: OFF, 2, 4, 6cm
Determine the regular in-
terval at which the time
should be printed in the
chart
Print the
channel numbers
Configuration level 2
➔ Print channel numbers
Spacing: OFF, 2, 4, 6cm
Determine the interval for
printing the traces in the
chart, labelled with the cor-
responding channel num-
bers
Report Configuration level 2
➔ Report
X Report
Type:
1-2
OFF, PERIODIC,
WEEKLY REPORT,
MONTHLY REPORT,
EXTERN.CONTACT
Select report/instance
number
Select type of report
Configuration level 2
➔ Report
Type: PERIODIC
Report time:
Interval
Enter any time
1, 2, 3, 4, 6, 8, 12, 24h
Enter start time for the first
report
Select a period
Configuration level 2
➔ Report
Type: WEEKLY
REPORT
Report time:
WEEKDAY:
Enter any time
MONDAY, TUESDAY,
WEDNESDAY,
THURSDAY, FRIDAY,
SATURDAY, SUNDAY
Enter time
Select weekday
Configuration level 2
➔ Report
Type: MONTHLY
REPORT
Report time: Enter any time
The report is made on the
first day of the month
Time at which the report is
made
Configuration level 2
➔ Report
Type:EXTERN.
CONTACT
The report is initiated by a
logic input
(Configuration level 3 Î
External report)
Parameter Value/selection Description
